● Determine the running cost your appliances. ● Make informed decisions when purchasing appliances and equipment. ● Reduce your electricity bill. ● Measure Voltage, Current, Power, Volts, Amps, Power Factor, and Greenhouse Gas Emissions. ● Calculate electrical expenses by day, week, month, and even an entire year.
|
|
|
|
|
Item
|
Range
|
Units
|
Accuracy
|
PM-10
|
PM-15
|
AC Voltage
|
100-240
|
V rms
|
±1%
|
AC Current
|
10
|
15
|
A rms
|
±1%
|
Power
|
0-2500
|
0-3750
|
W
|
±1%
|
Apparent Power
|
0-2500
|
0-3750
|
VA
|
±1%
|
Power Factor
|
0.001-1
|
|
Watt / (Vrms* Arms)
|
Frequency
|
45-65
|
Hz
|
±1%
|
Cost
|
0-9999999
|
$
|
|
Energy
|
0-99999
|
kWh
|
|
Gas
|
0-999999
|
kg
|
|
Cost Setting
|
0-99.999
|
kWh,cents/kWh
|
|
Gas Setting
|
0-9.999
|
kg/kWh
|
|
Time Duration
|
1,8,12,24
|
Hours
|
|
2,5,7,14,28
|
Days
|
|
Run-Time Measurement
|
99:23:59:59
|
Days:Hours: Mins:Sec.
|
|
Fuse rating
|
10A/250V 15A/250V
|
|
|
Dimensions
|
135(L) × 80(W) × 35(D)mm
|
Weight
|
Approx. 200g
|
Safety standards
|
EN 61010-1 EN 61326-1
|
|
|
|
